Texmate Panel Meter Controller FL-B101Q





144x36 metal surround case 144x36 NEMA4X clear cover

FL-B101Q

Base Price $316.00

144x36mm, Leopard, 101 Segment Bargraph.

Please note that in 2012 the headers were changed from 2-pin to 3-pin headers. This is differs to what is shown in the Product Manual. New header details here (PDF).

Features & Specifications

Download FL-B101Q Features & Specifications (PDF).

Product Information

Download FL-B101Q Full Manual (PDF).

Certifications, Awards, and Listings

The FL-B101Q is UL Listed.

Panel Cutout Adapter




Panel Cut-Out Trim Plate Set

equalizer Display Options

THR $11.00
101 segments, 1mm Red LED Bar, Horizontal, Top position
THG $33.00
101 segments, 1mm Green LED Bar, Horizontal, Top position
THB $39.00
101 segments, 1mm Blue LED Bar, Horizontal, Top position, Visible under bright sunlight
RVR $0.00
101 segments, 1mm Red LED Bar, Vertical, Right side
RVG $22.00
101 segments, 1mm Green LED Bar, Vertical, Right side
RVB $28.00
101 segments, 1mm Blue LED Bar, Vertical, Right side, Visible under bright sunlight
LVR $0.00
101 segments, 1mm Red LED Bar, Vertical, Left side
LVG $22.00
101 segments, 1mm Green LED Bar, Vertical, Left side
LVB $28.00
101 segments, 1mm Blue LED Bar, Vertical, Left side, Visible under bright sunlight
CVT $44.00
101 segments, 1mm Tri-Color LED Bar, Vertical, Center position
CVR $0.00
101 segments, 1mm Red LED Bar, Vertical, Center position
CVG $22.00
101 segments, 1mm Green LED Bar, Vertical, Center position
CVB $28.00
101 segments, 1mm Blue LED Bar, Vertical, Center position, Visible under bright sunlight
CHT $55.00
101 segments, 1mm Tri-Color LED Bar, Horizontal, Center position
CHR $11.00
101 segments, 1mm Red LED Bar, Horizontal, Center position
CHG $33.00
101 segments, 1mm Green LED Bar, Horizontal, Center position
CHB $39.00
101 segments, 1mm Blue LED Bar, Horizontal, Center position, Visible under bright sunlight
BHR $11.00
101 segments, 1mm Red LED Bar, Horizontal, Bottom position
BHG $33.00
101 segments, 1mm Green LED Bar, Horizontal, Bottom position
BHB $39.00
101 segments, 1mm Blue LED Bar, Horizontal, Bottom position, Visible under bright sunlight

power_input Power Supply

PS1 $0.00
85-265VAC/95-300VDC
PS2 $55.00
15-48VAC/10-72VDC

Choose Your Options ▲


Choose Your Options ▼

* One input module needs to be selected to complete the order.
* Factory pre-installed range is in bold type. For other standard ranges, select ZR under the Special Options tab.

AC

Single

IA06 $127.00 AC Volts True RMS, 3 ~ 600V AC

IA07 $127.00 AC mV True RMS, 3 ~ 200mV

IA08 $119.00 AC-mA True RMS, 2/20/200mA AC

IA09 $119.00 AC-Amps True RMS, 1 Amp AC

IA11 $127.00 AC-Amps True RMS, 5 Amp AC

IA3V $127.00 AC Volts True RMS, 30mV ~ 3V AC

DC and Process

Single

ID01 $75.00 DC-Volts, 2/20/200V/Custom w/24V DC Exc

ID02 $86.00 DC-Millivolt, 20/50/100/200mV DC w/24V DC Exc

ID03 $86.00 DC-Milliamp, 2/20/200mA DC w/24V DC Exc

ID04 $105.00 DC-Amps, 5A DC

ID05 $93.00 DC-Volts 2/20/200/Custom V DC w/Offset and 24V Exc.

ID07 $87.00 DC-Milliamp, 2/20/200mA DC w/Offset and 24V Exc

ID09 $105.00 DC-Amps, 1A DC

IP07 $86.00 Universal Process 2V/5V/10V/20V/200V/2mA/20mA/Custom

Linear/Position

Single

IR03 $75.00 Linear Potentiometer, 1kΩ min.

Pressure

Single

IGYZ $213.00 Universal Direct Pressure (Absolute or Differential/Gage).

IS01 $108.00 Strain Gage 5/10VDC Exc., 20/2mV/V, 4/6-wire

IS02 $108.00 Pressure 5/10VDC Exc., 20/2mV/V, 4/6-wire

IS04 $105.00 Pressure/Load Cell with External Excitation, 20/2mV/V, 4/6-wire

IS05 $108.00 Pressure/Load Cell, 20/2mV/V, 5/10V Excitation, 4-wire

IS06 $106.00 Pressure/Load Cell External Excitation, 20/2mV/V, 4-wire

Process

Single

IP01 $75.00 Process Loop, 4-20mA

IP02 $86.00 Process Loop, 4-20mA with 24VDC Exc

IP03 $86.00 Process Input, 1-5V DC with Offset, 24V Exc

Resistance

Single

IR05 $108.00 Resistance 2kΩ

Temperature

Single

IT03 $93.00 RTD, 100Ω Pt. 2/3/4-wire (-200 to 800°C) (Lynx only)

IT04 $93.00 RTD, 100Ω Pt. 2/3/4-wire (-200 to 1470°F) (Lynx only)

IT05 $93.00 RTD, 100Ω Pt. 2/3/4-wire (-199.0 to 199.0°F) (Lynx only)

IT06 $93.00 Thermocouple, J Type (0-1400 °F) (Lynx only)

IT07 $93.00 Thermocouple, K Type (0-1999 °F) (Lynx only)

IT08 $93.00 Thermocouple, J Type (0-760 °C) (Lynx only)

IT09 $93.00 Thermocouple, K Type (0-1260 °C) (Lynx only)

IT14 $93.00 RTD, 100Ω Pt. 2/3/4-wire (-199.0 to 199.0°C) (Lynx only)

special Input

Single

IA05 $118.00 AC-Amps Scaled RMS, 5 Amp AC

Custom Display Scaling

Qty Custom bar display scaling within standard ranges

Custom Faceplates and Labels for Meters

Artwork Data Recovery Fee (per serial number)
Add a customer's product code to the meter label.

Custom Legend on non-membrane type faceplate

Custom Meter Descriptor

Engineering Services

$

Input Range Change

Qty Input Range Change from Standard Range shown in BOLD Type. Please specify range when ordering.

Optional Faceplate Color

White background faceplate with black scale of 0 to 100.

Output Custom Scaling

Qty Custom analog output range, for 101Q, 202Q series bargraphs

Small Run Custom Faceplates for Meters and Bargraphs

Produce and install custom faceplate per meter - 1 color
Produce and install custom faceplate per meter - 2 color
Produce and install custom faceplate per meter - 3 color
Produce and install custom faceplate per meter - 4 color
One time charge for custom faceplate design with an assigned serial number. (per serial number)

Cases and Case Accessories

Connectors

Descriptor Adhesive

NEMA-4X Clear Lockable Water and Dust Proofing Cover
