Texmate Panel Meter Controller DI-50EB51





Texmate Tiger Configuration Utility

Open Tiger Meter/Controller Configuration Utility Instruction (PDF)

Download Free Tiger Meter/Controller Configuration Utility Software for Windows
(This software requires a Serial Output option
in order to be used. No technical support is offered for this software.)

DI-50EB51

Base Price $543.00

96x48mm, Tiger, 5 Digit, 51 Segment bargraph, 96x48mm (3.78"x1.89"), Depth behind bezel: 117mm (4.61"), E Version

Features & Specifications

Download DI-50EB51 Features & Specifications (PDF).

Product Information

Download DI-50EB51 Full Manual (PDF).

Certifications, Awards, and Listings

The DI-50EB51 is UL Listed.
